Roughneck E1049 Series Heavy Duty Male and Female Standard Connectors 444 MCM - Ideal for Industrial Electrical Wiring and Power Distribution Systems

These Roughneck™ E1049 series connectors are made rugged and hardy, ideal for land based drilling applications. They are designed to withstand heavy abuse all the while maintaining a safe and secure connection.

Benefits and Features

• Contacts machined from solid copper and specially plated for corrosion resistance and superior conductivity
• Color-coded rubber insulator provides quick visual identification of circuit and phase connections
• Watertight insulators provide maximum protection
• Male and female contacts are assembled to cable with standard crimp tools
• Drive pins on contacts securely lock it to the insulator
• Male contacts are equipped with safe front insulated tip

• Cable Size: 444 MCM
• Voltage Rating: 1000 V AC/DC
• Amperage Rating: Up to 796 Amps continuous
• Ampacity rating at 40° ambient: 642 Amps at 90°C - 796 Amps at 125°C
• Material - Insulator: Rubber
• Material – Receptacle Shell: epoxy powder coated aluminum alloy
• Material – Hardware: Stainless Steel
• Material – Contact: Copper • NEMA 3
